Applications: - Steel Production
- Waste Incineration
- Heat Treating
- Salt Baths
- Rotary Kilns
Base Metal Thermocouples are tried and true temperature measurement devices that have stood the test time. Rugged, durable industrial thermocouple assemblies designed for use in the most severe process environments and temperatures up to 2300°F (1260°C). Base metal thermocouples are the most commonly used category of thermocouples and are made of common and inexpensive meals such a Nickel, Copper and Iron.
Twisted and welded or butt weld junctioningStraight or bent assembliesAdditional sheathing for extreme environment like those found in molten salt bathsCEL only supplies MgO thermocouples that meet or exceed special limits of error.Cleveland Electric Laboratories builds Base Metal Assemblies and Elements to order with added protection tubes, process fittings, transitioned to soft wire or in thermowells. Termination on the cold end includes industry-standard plugs/jacks, bare leads, terminal blocks, or protection heads. For the hot end, the junctions may be grounded, ungrounded or an exposed junction either twisted and welded or in a butt weld configuration. These optional accessories are in stock and can be configured and built to suit your exact needs.
Base Metal Assemblies (BMAs) and Base Metal Elements (BMEs) are designed for the most severe environments. As noted by name, Base Metal includes Type E, J, K, M, N and T calibrations. Offered in a wide variety of protection tubes and hardware, our Base Metal products offer durability, accuracy and response for your unique application.
Twisted and welded or butt weld junctioningStraight or bent assembliesAdditional sheathing for extreme environment like those found in molten salt bathsCEL only supplies MgO thermocouples that meet or exceed special limits of error.Cleveland Electric Laboratories builds Base Metal Assemblies and Elements to order with added protection tubes, process fittings, transitioned to soft wire or in thermowells. Termination on the cold end includes industry-standard plugs/jacks, bare leads, terminal blocks, or protection heads. For the hot end, the junctions may be grounded, ungrounded or an exposed junction either twisted and welded or in a butt weld configuration. These optional accessories are in stock and can be configured and built to suit your exact needs.
Base Metal Assemblies (BMAs) and Base Metal Elements (BMEs) are designed for the most severe environments. As noted by name, Base Metal includes Type E, J, K, M, N and T calibrations. Offered in a wide variety of protection tubes and hardware, our Base Metal products offer durability, accuracy and response for your unique application.
